MOTHEBOARD

MOTHERBOARD

WHAT IS A MOTHERBOARD?

A motherboard is the main circuit board of a computer. It acts as the central hub that connects and allows communication between all hardware components, including the CPU, RAM, graphics card, storage drives, and more. It powers and links everything together, making the system function as one unit.

WHY THEY ROCK?

• Connect Everything: The motherboard links all major parts so your CPU, RAM, GPU, and storage can work together smoothly.

• Power Distributor: It delivers power to each component, keeping the system running.

• Upgrade Friendly: With expansion slots, you can add more features like a better graphics card or extra storage.

COMPONENTS OF A MOTHERBOARD

• CPU Slot: Holds and connects the CPU to the motherboard. Often comes with a lock and a heat sink to manage heat.

• RAM Slots: Slots for installing memory (RAM) modules. Most boards have 2 to 4 slots.

• Expansion Slots: Also known as bus or card slots (PCI, AGP, etc.), they let you add extra hardware like sound or network cards.

• Capacitor: Stores and releases electrical energy. Looks like a small cylinder on the board.

• Inductor (Coil): Stores magnetic energy and helps manage power flow.

• Northbridge: Controls communication between the CPU, RAM, graphics, and the southbridge.

• Southbridge: Manages input/output devices like USB ports, and communicates with the northbridge.

• USB Ports: Connect external devices like a keyboard, mouse, or printer.

• PCI Slot: Used for connecting add-on cards like network or sound cards.

• AGP Slot: A special slot for high-performance graphics cards (now outdated).

• Heat Sink: Absorbs and disperses heat from the CPU to keep it cool.

• Power Connector: Connects to the power supply to energize the motherboard and its components.

• CMOS Battery: Powers BIOS settings and system clock when the PC is off.

• Integrated Circuits (ICs): Tiny chips that handle data processing and communication across the motherboard.

TYPES OF MOTHERBOARDS

1. AT Family (Advanced Technology)

• Used from the 1980s to early 2000s.

• Large in size, with 6-pin power connectors that were hard to work with.

• Now mostly obsolete.

2. ATX Family (Advanced Technology Extended)

Most common modern motherboard type:

Standard ATX

• Size: ~305 x 244 mm

• Plenty of slots for RAM and expansion cards.

• Great airflow due to its larger size.

Micro ATX

• Size: ~244 x 244 mm

• Fewer expansion options, but compact and cost-effective.

Extended ATX (E-ATX)

• Size: ~344 x 330 mm

• Supports dual CPUs, more RAM slots (up to 8), and more PCIe ports. Ideal for high-end builds.

Flex ATX

• Smallest in the ATX family.

• Designed for compact and budget systems.

3. BTX Family (Balanced Technology Extended)

Created for better airflow and heat control.

• BTX: Larger than ATX, but discontinued by Intel.

• Pico BTX: Smaller version, used for digital devices with minimal expansion needs.

4. ITX Family (Information Technology Extended)

Great for small and energy-efficient builds.

Mini ITX

• Size: 170 x 170 mm

• Popular since early 2000s for compact systems.

Mini STX

• Size: 147 x 140 mm

• Even smaller, introduced in 2015 for ultra-compact PCs.

TIPS FOR CHOOSING A MOTHERBOARD

• CPU Compatibility: Make sure the socket type matches your CPU (Intel or AMD).

• RAM Slots: Choose a board with enough RAM slots for your needs.

• Ports & Expansion: More USB and PCIe slots = more options for upgrades.

• Size: Pick the right size (ATX, Micro ATX, Mini ITX) to fit your PC case.

CONCLUSION

The motherboard is the heart of your computer, connecting all hardware so they work together efficiently. Choosing the right motherboard depends on your needs—like CPU type, upgrade options, and size. Whether you're building or upgrading a PC, selecting the right motherboard is a key step to ensuring system performance and future flexibility.

general information

PROCESSOR

What is a Processor?

The processor is the brain of the system. It processes everything that happens on the PC and executes all the actions that take place. The faster the processor a computer has, the quicker it will carry out the commands given to it. This component is part of the hardware in many devices, not just your computer.

Types of Processors

Single-Core Processors:

This is the oldest type of computer CPU, used mainly in the 1970s. It contains only one core that performs operations. A single-core CPU can process only one task at a time, making it inefficient for multitasking.
Dual-Core Processors:
A dual-core CPU has two cores on a single chip. Each core has its own cache and controller, and they work together as one unit. Dual-core processors are faster and better at multitasking than single-core CPUs.
Quad-Core Processors:
A quad-core processor contains four independent cores on a single chip. These cores can read and execute different instructions simultaneously, making them much better for multitasking and handling complex tasks.

---

Main Components of a Processor (CPU)

Control Unit (CU):

Directs the operations of the processor and manages data flow within the CPU.

Arithmetic Logic Unit (ALU):

Performs basic arithmetic operations (like addition and subtraction) and logical operations (like AND, OR, comparisons).

Registers:

Small, high-speed memory areas inside the CPU that temporarily hold data during processing.

Cache Memory:

Very fast memory that stores frequently accessed data and instructions to speed up processing.

Clock:

Produces timing signals that synchronize operations inside the processor. Measured in gigahertz (GHz).

Buses:

Communication lines that transfer data, instructions, and signals within the CPU and to other system components.

Instruction Decoder:

Converts instructions from memory into signals to control different parts of the CPU.

Floating Point Unit (FPU):

Handles advanced mathematical calculations, especially those involving real numbers and decimals.

WHICH PROCESSOR SHOULD YOU SELECT?

Which Processor Should You Select?

Make sure your motherboard is compatible with the processor you plan to install. If not, you’ll need to upgrade either the motherboard or the processor.

Here’s a simple guide:

• AMD Ryzen 3 / Intel Core i3:Great for basic tasks and budget-friendly computers.

• AMD Ryzen 5 / Intel Core i5:Ideal for everyday use and balanced performance.

• AMD Ryzen 7 / Intel Core i7:Good for gaming and light content creation.

• AMD Ryzen 9 / Intel Core i9:Best for high-end gaming, video editing, and demanding professional tasks.

CONCLUSION

The processor is the brain of the computer that runs programs and handles all operations. Intel and AMD are the two main manufacturers. Processors come with different numbers of cores—the more cores, the more powerful the processor. Choose the right processor based on your computing needs and your budget.

general information

HOW TO BUILD YOUR OWN COMPUTER

GENERAL INFORMATION OF A COMPUTER

Learning how to make your own coputer sound hard, but it’s actually easier than it seems. You don’t need to be a teacher or an expert  just a little time and curiosity. Whether you want to make websites, apps, or fun projects, coding can help you do it. In this blog, you will find simple steps and tips to help you get started, even if it’s your first time.

GENERAL COMPONETS :

Processor (CPU)

Motherboard

RAM (Memory)

Case (Tower)

Hard Drive (HDD) / SSD

Graphics Card (GPU)

Power Supply (PSU)

Cooling System / Fans

PERIPHERALS:

- INPUT:  scaner, keyboard, mouse, microphone, joystick, camera.
-OUPUT: printer, monitor, speakers, headphones.
